Band Pass Filter - IF-820

Item #: SOF909023
Regular price: $255.00
Contact us for order info.

Product Description

This product is no longer available.
Please contact customer service an alternative.


λc = 820nm ±2nm
HW = 10nm±2nm
Tpeak = 50%
Brange = 300-1,200nm OD4 blocking


λc = Cut-on wavelength at which transmission is 50% Tpeak
HW = Half-width at 50% Tpeak
Tpeak = Minimum Peak Transmission in (%)
Brange = Blocking spectral range with OD# except for band pass
OD = Attenuation of transmittance by 10OD#


Features

  • Narrow bandpass in near-infrared band
  • Excellent in-band transmission
  • Sharp transition assures precise blocking (typical)

Requires a filter holder for use with the 7215 or 7290A series.
Please order:
- F25 Filter Holder for 7215 series ElectroViewers
or
- G25 Filter Slide for 7290 series MicronViewers
