Q-Switch 27 MHz, 6.5 Aperture
Product Description
Operating Specifications
| Operating wavelength: | 1064nm |
| Operating frequency: | |
| (QS24) | 24MHz |
| (QS27) | 27MHz |
| Active aperture: | 4 x 15mm |
| (6.5 x 15mm optional) | |
| VSWR: | 1.1:1 |
| Interaction material: | Fused Silica |
| A.R. Coating reflectivity: | <0.1% per surface |
| Damage threshold: | >500MW /cm2 |
| Diffraction Efficiency: | >40% at 50W r.f. |
| Max. continuous drive power: | 100W |
| Polarization: | Any |
Mechanical Specifications
