Q-Switch 27MHz RETROFIT KIT, 4mm Shear, 6mm RA Push Fittings, Metric Mount with hardware

The kit is designed to replace/retrofit most common 27 Mhz Q Switches manufactured by Gooch & Housego and others. This Q-switch kit comes with a 27Mhz Q-switch with 6mm quick-connect water fittings, but it also comes with adapters for the screw fitting connectors and barbed connectors used by many manufacturers, like Lee Laser, Control Laser, US Laser, Laser Applications, Rofin Sinar, and many other OEMs.

Q-Switch Specifications

Interacton Material :

Fused Silica

Wavelength :

1047 to 1064nm

Anti-Reflection Coating :

< 0.2% per surface

Damage Threshold :

> 1GW/cm2

Transmission (single pass) :

> 99.6%

Frequencies Available :

27.12Mhz

VSWR :

< 1.2:1 (50 ohm imput impedance)

Active Apertures Available :

3mm, 4mm, 5mm, and 6.5mm

Clear Aperature :

6.5mm

Window diameter :

15mm

Mounting Options :

6-32 or M3 tapped holes, 4mm deep

Acoustic Mode :

Shear or Compression (Longitudinal)

Rise-Time / Fall - Time :

173ns/mm (shear)

RF Power Rating :

15W - 100W C.W.

RF Input Connector :

BNC - Female (SMC - Male Available)

Water Flow Rate :

0.2 Ltr/Minute, Minimum

Maximum Water Temperature :

+40°C (recommended, 22°C to 32°C), a few degrees above room temp. to prevent condensation.

Water Connectors :

6mm RA Push Fittings

Thermal cut-off connection :

SMC - Male

Housing / Flow Chamber Material :

Aluminum

---

Mechanical Specifications
